Catalac is a defunct English maritime construction company that specialized in building sailing catamarans. The company was founded by Tom Lack (hence "Cata + Lac"), in Christchurch, Dorset. After a successful period of production, the company closed in 1986. In the 1990s, the Catalac 9M was briefly revived and updated in the US as the "Catalac 900".
The Catalac company's main model was the 9-metre 9M. All the other models are derived from the 9M and use a similar design concept; All Catalacs were very strongly-built with thick GRP hulls and glass windows. Some of the superstructure, such as the solid foredeck, was of sandwich GRP construction. Compared to modern designs, Catalacs had a narrow beam of less than half the and vertical transoms. Initially featuring lifting dinghy-type rudders, Catalac moved to fixed rudders protected by a skeg; this allowed the boats to sail a little closer to the wind. Only the 9M has a staggered sheerline the other models all have an unbroken sheerline.
The sailplan is a masthead Bermuda sloop of modest area. Although modern catamarans tend to have a fractional rig, the Catalac's mainsail has a straight leech, short battens and no roach. Twin backstays run to the transoms, enabling the forestay to be kept taut. There are no known examples of a Catalac ever pitchpoling or being blown over and upturned.
Widely-flaring chines and overhanging bows.
"V" Hull underwater profile to allow maneuverability and skidding to leeward under high winds.
Solid foredeck with no trampoline.
Twin inboard diesels (sited aft), or single centrally-placed steered outboard.
Aft cockpit with protected wheel steering.
Conventional accommodation, with two main berths on the bridgedeck forward of the saloon.
Occasional single berths further aft in the hulls.
Galley-below layout (in the port or starboard hull).
Single head & shower room.
Roller furling on the forestay.
Catalacs have been very well-received. In Cruising in Catamarans Charles Kanter declared that the Catalac "27 and 30 are among the best cruising catamarans ever produced". Kanter wrote,"when sailing in a 41-foot Catalac 12M alongside a beautiful 55 foot gold-plate ketch, Pacific High, we loped along with a steady upright forward motion and in 3 hours they were hull down over the horizon. In 16 hours we had covered 140-odd miles". In Catamarans for Cruising, Jim Andrews praises the 9M's interior layout and its good sea-keeping qualities. A Practical Boat Owner magazine review of a Catalac 9M summarised it as a "competent, versatile and long-lasting cat".
Overall, 255 Catalac 9M boats were made, making it the most successful model in the range. The other production figures are: 8M - 216 built; 10M - 45 built; 11M - (no data); 12M - 27 built.
LWL: 25' 4"
Beam: 13' 8"
Draft: 2' 4"
Displacement: 6,000 lbs (dry)
Sail area: Main 260 sq ft, Jib 348 sq ft
LOA: 29' 3"
LWL: 25' 4"
Beam: 13' 9"
Draft: 2' 6"
Displacement: 8,000 lbs
Sail area: Main 270 sq ft, Jib 348 sq ft
LOA: 33' 8"
Beam: 15' 3"
Draft: 2' 9"
Displacement: 11,000 lbs (dry)
Sail area: Main 283 sq ft, Genoa 333 sq ft
LOA: 35' 9"
LWL: 28' 3"
Beam: 15' 5"
Draft: 2' 9"
Displacement: 13,000 lbs (dry)
Sail area: Main 305 sq ft; Genoa 333 sq.ft
LOA: 40' 10"
Beam: 17' 6"
Draft: 3' 1"
Displacement: 18,500 lbs (dry)
Sail area: Main: 336 sq ft, Genoa 410 sq ft
